OPTO2S

Position control for doors / casings on hazardous machinery Contactless encoded electronic sensor with relay Category 3 total safety management without an external controller 12V version for embedded applications

• Level of performance without an external controller: PL = c
• Level of performance with AWAX controller: up to PL = e
• Safety category without an external controller: 1
• Cycle before dangerous failure: B10d = 2,000,000 at 50mA
• Max. activation distance: 10 mm, 2 mm hysteresis
• Safety contacts: 2 x NO 250 mA/48V redundant
• Detection encoding: mono-code inviolable
• Indicator: LED indicates code recognition
• Reset: automatic
• Attachment: 4 tamper-proof M3 screws (optional ref: BH3)
• Mounting position: 2 (double wall brackets)
• Material: PA6
• Electrical Connection: 3, 6, 12m cable (UL2464 PVC)
• Water resistance: IP 68
• Temperature: -20°C to +60°C
• Marking: pad printing + serial no. for traceability
